Upgraded Knox Powerwall 3.0 25.6V 100Ah LiFePO4 Lithium Battery – 2.56kWh Wall Mounted Solar Storage with WiFi, LCD Display & 6000+ Cycles
Original price was: ₨ 149,999.00.₨ 126,999.00Current price is: ₨ 126,999.00.
Buy Knox Powerwall 3.0 25.6V 100Ah LiFePO4 lithium battery with smart LCD display, built-in WiFi, A+ REPT cells, PACE BMS, 6000+ cycles, inverter compatibility, and 5-year warranty for solar backup systems.
You’re now subscribed to price tracking for this product. We’ll notify you if the price drops.
Upgraded Knox Powerwall 3.0 25.6V 100Ah LiFePO4 Lithium Battery
The Knox Powerwall 3.0 (Model LIO 2.56-IP20) is an upgraded 2.56kWh wall-mounted lithium battery engineered for superior efficiency, long-term reliability, and stable solar energy storage performance. Built using A+ world-class REPT LiFePO4 prismatic cells and an intelligent PACE Battery Management System (BMS), it delivers safe daily operation for residential and small commercial solar systems.
Designed for modern solar applications, this battery features smart LCD monitoring, built-in WiFi connectivity, 1C charge/discharge capability, and broad inverter compatibility for smooth integration with hybrid and off-grid systems ⚡🔋
Upgraded Key Features
🔋 25.6V – 100Ah High-Capacity Storage
- Nominal Voltage: 25.6V
- Capacity: 100Ah
- Total Energy: 2.56kWh
Ideal for home backup power and daily solar energy storage.
📟 Smart LCD Display
Real-time LCD display shows:
- Battery voltage
- SOC (State of Charge)
- Temperature
- Alarm status
- Charging/discharging data
📶 Built-in WiFi Connectivity
Integrated WiFi allows easier remote battery monitoring and system visibility.
⚡ 1C Charge & Discharge Performance
- Fast charging capability
- Stable output under high load
- Better inverter response
🔁 6000+ Life Cycles
- More than 6000 cycles @ 80% DOD
- Long design life up to 10 years service warranty
🧠 A+ World Top Cells & Smart BMS
- REPT A-grade prismatic LiFePO4 cells
- PACE intelligent BMS with cell balancing
- Improved safety and lifespan
🔌 Compatible with All Major Inverters
Supports leading brands including:
- Growatt
- Deye
- Solis
- GoodWe
- SMA
- Victron Energy
🛡 Warranty Protection
- 5-Year Official Warranty
- 10 Years Service Support
Technical Specifications
| Specification | Details |
|---|---|
| Model | LIO 2.56-IP20 |
| Battery Type | LiFePO4 Lithium Iron Phosphate |
| Cell Brand | REPT A-Grade Prismatic Cells |
| Nominal Voltage | 25.6V |
| Capacity | 100Ah |
| Energy | 2560Wh (2.56kWh) |
| Configuration | 8S1P |
| Charge Cut-Off Voltage | 28.8V |
| Discharge Cut-Off Voltage | 22V |
| Max Charge Current | 100A |
| Continuous Discharge Current | 100A |
| Peak Discharge Current | 120A |
| Recommended Discharge Current | 50A |
| Recommended DOD | 80% |
| Cycle Life | 6000+ Cycles |
| Series Support | Max 2 Units |
| Parallel Support | Max 4 Units |
| Communication | RS485 |
| Display | LCD Screen |
| BMS | PACE Intelligent BMS |
| Protection | IP20 |
| Weight | 25.1 ± 0.5 kg |
| Dimensions | 350 × 180 × 450 mm |
Advanced Protection Features
✔ Over-charge protection
✔ Over-discharge protection
✔ Over-current protection
✔ Short-circuit protection
✔ High temperature protection
✔ Low temperature protection
✔ Intelligent cell balancing
Environmental Conditions
| Parameter | Range |
|---|---|
| Charge Temperature | 0°C to +55°C |
| Discharge Temperature | -20°C to +60°C |
| Storage Temperature | 5°C to +35°C |
| Humidity | 40% – 80% |
Applications
🏠 Home solar backup systems
🏢 Office backup power
⚡ Hybrid inverter battery storage
🔋 Load shedding backup
🌞 Off-grid solar solutions
Why Choose Knox Powerwall 3.0
- Compact wall-mounted design
- Premium A+ cells
- Stable inverter communication
- Long battery lifespan
- Maintenance-free operation
- Smart monitoring features
